SCP206 Compact dual-channel power amplifier - 2 x 60W @ 4 Ohm - 120W @ 70/100V
MSRP:
POA
SCP206
Uncommon strength, common sense
The SCP series are a range of extremely powerful compact dual-channel power amplifiers for commercial use. These half 19” devices can be used in stereo low impedance or 70/100V bridge mode. There are 5 different models to serve a wide range of applications with power ratings that vary between 120W up to 1000W in a half 19” rack space housing.
The compact and elegant design of the half 19” rack space enclosure allows for single installation in a 10.5” equipment rack, or side-by-side (two devices) in a 19” equipment rack. Of course, desktop installation or mounting in an equipment rack using the MBS310 series mounting adapters is possible.
You may wonder if so much power in such a small enclosure could cause some heating issues? Not at all, the SCP series are designed in a unique way so that optimal cooling is established, this by passive cooling on the SCP206 and SCP212 and active cooling on the SCP224, SCP230 and SCP250 in order to improve thermal comfort without the need for additional actions.
A connection to the WP2xx series input wall panels (see page 76) or volume controllers can be made via the RJ45 connector on the back of the SCP. This allows for a cost-effective plug & play solution to extend or introduce brand new input possibilities and control options.
Equipped with a standby mode switch, the SCP series will enter an energy-saving standby mode after a period of inactivity making it unique in the market. This feature together with the overall energy efficient design makes the SCP meet the high standards of the Energy star certification.
When you combine the SCP series with a suitable pre-amplifier or wall-mounted input panel you create a relatively powerful and complete solution for background music installations.
- Compact and lightweight design
- Compatible with WP2xx series remote wall input panels
- Energy-saving standby mode
- Stereo low impedance or 70/100V bridge mode
- Unique optimal cooling
| RMS/AES power handling | @ 4 Ω Stereo | 2 x 60 W | |
| @ 8 Ω Stereo | 2 x 30 W | ||
| @ 70/100 V Bridge | 120 W | ||
| Frequency | Response (± 3 dB) | 20 Hz - 20 kHz | |
| THD+N (@ 1 kHz) | <0.05% | ||
| Signal / Noise | > 95 dB | ||
| Indicators | VU LED bar (front) | ||
| Outputs | Voltage / Impedance | 70-100 V / 4 Ω | |
| Connector | 4-pin Euro Terminal Block (Pitch - 5.08 mm) | ||
| Inputs | Connector | 3-pin Euro Terminal Block (Pitch - 3.81 mm) | |
| IEC C14 Connector | |||
| Other | Connector | RJ45 | |
| Type | 1 x Remote Volume controller | ||
| 1 x Remote Wall Mixer | |||
| Stereo - BTL/HPF mode configuration | |||
| Priority mute contact | |||
| Power | Standby switch | ||
| Supply | 100 ~ 240 V AC / 50 ~ 60 Hz | ||
| Control | Gain control potentiometers (rear) | ||
| Stereo Low Z & Mono High Z switch | |||
| 70/100V switch | |||
| Cooling | Convection cooled | ||
| Technology | Class-D | ||
| Construction | Steel | |
| Dimensions | 217.5 x 44 x 300 mm (W x H x D) | |
| Mounting | 1/2 19” / 1 HE or tabletop | |
| Weight | 2.70 kg | |
| Accessories | Optional | 19” Rackmount adapter |
| WP2xx Universal wall pan | ||
*Note: AUDAC operates a policy of continuous development. AUDAC reserves the right to make changes and improvements to any of the products described on this website without prior notice. Specifications are subject to change without notice. Please refer to the manufacturer's web page for the most up-to-date specifications and product details www.audac.eu For the most up-to-date Software and Firmware visit www.audac.eu.
