AMP22 Mini stereo amplifier 2 x 15W, balanced line & Mic + WP2XX input
MSRP:
POA
AUAMP22
Mini stereo amplifier 2 x 15W, balanced line & Mic + WP2XX input
The AMP22 is a mini stereo power amplifier with a power rating of 2 x 15 Watt, that lends itself perfectly to small speaker systems requiring compact and economical audio solutions. It offers the ideal solution for applications such as classrooms, offices, and meeting rooms where only a small amount of speakers are required.
The compact size and very high efficiency make it perfectly suited to be hidden in a closet, on a false ceiling, or mounted under a desk or table. The combination of the stereo balanced line, with microphone input, makes it perfectly suited for applications where it should be used in combination with projection screens and video sources while a microphone is connected. Two gain potentiometers make it possible to control the sensitivity and balance between music and speech, while a switch allows bridging of the output channels to obtain one channel with merged output power.
A remote wall mixer can be connected for applications where local mixing for the inputs is desirable, while large distances can be covered between the source and amplifier using simple CAT5E or higher twisted pair cabling. The volume controller input allows the connection of an additional wall controller for overall volume control.
The Class-D amplifier technology, standby mode and included switching power supply makes this device compliant with the highest energy efficiency and environmental requirements. A variety of optionally available mounting brackets for the AUDAC S-Box product range are allowing desk, closet, or 19” equipment rack installation.
Highlights
- Compatible with WP2xx series
- Class-D amplifier technology
- Energy-star certified
- Compact and lightweight design
Applications
- Corporate
- Bars & Restaurants
- Retail
| RMS/AES power handling | @ 4 Ω Stereo | 2 x 15 W | |
| @ 8 Ω Stereo | 2 x 7.5 W | ||
| @ 8 Ω Bridge | 30 W | ||
| Inputs | Balanced Stereo | Type | 1 x Stereo Balanced Line |
| Connector | 2 x 3-pin Euro Terminal Block (Pitch - 3.81 mm) | ||
| Impedance | 20 kΩ | ||
| Sensitivity | -12 dBV ~ +12 dBV | ||
| Balanced Microphone | Type | 1 x Balanced Microphone | |
| Connector | 3-pin Euro Terminal Block (Pitch - 3.81 mm) | ||
| Impedance | 47 kΩ | ||
| Sensitivity | -50 dBV ~ -18 dBV | ||
| Other | Connector | RJ45 | |
| Type | 1 x Remote Volume controller | ||
| Connector | RJ45 | ||
| Outputs | Type | 1 x Stereo Loudspeaker | |
| Connector | 4-pin Euro Terminal Block (Pitch - 5.08 mm) | ||
| THD+N (@ 1 kHz) | < 0.1% | ||
| Crosstalk (@ 1 kHz) | < -75 dB | ||
| Signal / Noise | > 95 dB | ||
| Power | Consumption | Standby | 0.8 W (PSD241 included) |
| Supply | 24V DC (PSD241 switching Power supply included 100 ~ 240V AC / 47 ~ 63 Hz) | ||
| Efficiency | 87% | ||
| Cooling | Convection cooled | ||
| Protection | Overheating | ||
| Overload | |||
| DC Short circuit | |||
| Signal limiting | |||
| Energy certification | Energy Star 3.0 | ||
| Dimensions | 4.25" x 1.73" x 6.49" (108 x 44 x 165 mm) (W x H x D) | |
| Weight | 1.76 lbs (0.800 kg) | |
| Accessories | Included | PSD241 - Power supply 24V / 1.67 A (Efficiency Level V) |
| Optional | VC3208 Remote volume controller | |
| MBS1xx Optional Wall mounting brackets | ||
| TR3030 100V Transformer 30 W | ||
| WP2xx Universal wall panel | ||
*Note: AUDAC operates a policy of continuous development. AUDAC reserves the right to make changes and improvements to any of the products described on this website without prior notice. Specifications are subject to change without notice. Please refer to the manufacturer's web page for the most up-to-date specifications and product details www.audac.eu For the most up-to-date Software and Firmware visit www.audac.eu.
